SIGLENT Introduces a New Flagship Line of Oscilloscopes with 2 GHz Bandwidth and Advanced Capabilities

SIGLENT Technologies has introduced another new high performance line of test instruments with the SDS6000A series of oscilloscopes, available with a maximum bandwidth of 2 GHz. In addition to the higher bandwidth, the device offers 5 GS/s per channel and an interpolation technique ESR (Enhanced Sample Rate) is implemented for equivalent sample rates up to 10 GS/s per channel, which significantly improves the quality of the acquired signals. This is also the first SIGLENT oscilloscope with an ADC per channel. This enables the scope to maintain a high sample rate, regardless of the number of channels activated.

The newly designed input stage delivers great performance (SFDR = 45 dBc, channel-to-channel isolation up to 70 dB, DC amplifier accuracy +/- 1.5%). This allows even the smallest signals on the lowest vertical range (500 µVdiv) to be captured precisely. Furthermore, the implemented HiRES (High Resolution) functionality improves the vertical resolution from 8 bits to up-to 16 bits and enhances the signal acquisition accuracy.

The SDS6000A oscilloscopes are available in 500 MHz, 1 GHz and 2 GHz bandwidths. The acquisition memory has a maximum size of 500 Mpts and is distributed over 1, 2 or 4 channels. The waveform capture rate can reach up to 750,000 waveforms / s in sequence mode. Together with the digital trigger and extensive trigger types, rare events can be isolated quickly and efficiently. The zone trigger offers enhanced flexibility by delivering two user-defined zones that can be positioned individually and used in inclusive or exclusive modes. The analysis can be carried out using many implemented measurement functions including a formula editor and four mathematical curves.

As with all Siglent oscilloscopes, the “history” function, mask test, Bode plot and a bundle of serial bus decoders (I2C, SPI, UART, CAN, LIN) are implemented as standard in this series. The SDS6000A can optionally be expanded by 16 digital channels and an external function generator (25 MHz). Additional serial bus decoders (CAN-FD, FlexRay, MIL1553, I2S, SENT, Manchester) are also available.
