Marsquakes reveal the anatomy of the Red Planet’s interior

Seismic waves from quakes detected by NASA’s robotic InSight lander have helped scientists decipher the anatomy of Mars, including the first estimates of the size of its large liquid metal core, thickness of its crust, and nature of its mantle. The findings disclosed on Thursday shed light on what had been a poorly understood internal structure of Earth’s smaller neighbor and provided a few surprises as well as confirmation that the Red Planet’s center is molten.

The InSight lander, which touched down in 2018 to begin the first mission to study the deep interior of Mars, has detected more than 700 marsquakes, most of modest strength. Waves generated by quakes vary in speed and shape when journeying through different material inside a planet.

I’ve mapped the interior of Mars for the first time and found some surprises:

– Crust: thinner than expected, with maybe two or three sub-layers
– Mantle: a single layer (969 mi/1,560 km), simpler than Earth’s
– Core: larger than expected (1,137 mi/1,830 km radius), and molten pic.twitter.com/cLgQVkwBnz

— NASA InSight (@NASAInSight) July 22, 2021

Data from InSight’s seismometer instrument covering about three dozen marsquakes enabled the contours of the planet’s interior to come into focus.

“The real importance of these findings is that, for the first time, we actually have measurements of dimensions – sizes – of the fundamental building blocks of the planet Mars,” said planetary geophysicist Bruce Banerdt of NASA’s Jet Propulsion Laboratory, the InSight mission’s principal investigator. “Before this, all we had were comparisons with Earth, theoretical calculations and indirect inferences from other observations like the trace isotope chemistry of Martian meteorites,” Banerdt added.

Clouds drift over the dome-covered seismometer, known as SEIS, belonging to NASA’s InSight lander, on Mars. (NASA/JPL-Caltech)

The Martian core, the innermost geologic layer, was found to have a diameter of approximately 2,275 miles (3,660 km), larger than previously thought. This suggests that the core, made up mostly of iron and nickel, is less dense than previously known, with lighter elements such as sulfur, oxygen, carbon and hydrogen representing an unexpectedly large proportion. The Martian crust, the outermost layer, is geologically quite different from Earth’s.

Our planet’s crust is divided into immense plates that move inexorably over a rocky inner layer called a mantle in a process called plate tectonics. Crust at certain spots below Earth’s oceans is constantly recycled. “Since we don’t have active plate tectonics on Mars, nothing similar is happening there. This also means that the crust of Mars is very old,” said seismologist Brigitte Knapmeyer-Endrun of the University of Cologne in Germany, who led one of the three studies on the Martian interior published in the journal Science.

The global average crust thickness was found to be 15-50 miles (24-72 km). There was significant variability in the thickness, with a difference of roughly 60 miles (100 km) between the minimum in a region called the Isidis impact basin and the maximum beneath a region called the Tharsis volcanoes.

“The crust at the landing site consists of at least two layers, and the global average crustal thickness is less than predicted by some previous models. The crust is rather thin,” Knapmeyer-Endrun said.

🚨New science results! 🚨

I’ve been listening carefully to Mars for over two years, and have detected hundreds of quakes. Join my science team for a live chat Friday, July 23 at 9 a.m. PDT/12 p.m. EDT, to hear what they’ve discovered. https://t.co/Nvk9AfSAKu

— NASA InSight (@NASAInSight) July 22, 2021

Earth’s crust thickness also varies, between almost zero near deep underwater mid-ocean ridges, where new crust is formed, to about 50 miles (80 km) beneath the Himalayas. The Martian mantle, sandwiched between the crust and core, extends roughly 970 miles (1,560 kilometers) below the surface. Its composition differs from Earth’s, suggesting the two planets arose from different material when they formed more than 4.5 billion years ago. Mars, the fourth planet from the sun, has a diameter of about 4,220 miles (6,791 km), compared to Earth’s diameter of about 7,926 miles (12,755 km).

Banerdt said the new findings allow scientists to test theories of planet formation. “The understanding we will gain from this,” Banerdt said, “will apply not only to Mars but to the formation and history of the Earth and any other rocky planet in our solar system or beyond.”
